Professional and precise product catalogs will surely provide long-term, robust support for the sustained growth of your business performance.
Please contact us if you require the complete product catalog.
Catalog Search：
-
Ref.:52089275AB
Rear Axle
Height : 66.5 mm
Diameter : 319.8 mm
Centering Diameter : 72 mm
Pitch Circle Diameter : 127 mm
Brake Disc Thickness : 14 mm
Minimum Thickness : 12.4 mm
Num. of holes : 5
Solid or Vented : S
Weight : 8 kg -
Rear Axle
Height : 57.2 mm
Diameter : 334 mm
Centering Diameter : 70.9 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 14 mm
Minimum Thickness : 12 mm
Num. of holes : 5
Solid or Vented : S -
Front Axle
Height : 55 mm
Diameter : 302 mm
Centering Diameter : 72 mm
Pitch Circle Diameter : 127 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26.4 mm
Num. of holes : 5
Solid or Vented : V
Weight : 7.3 kg -
Ref.:52060147AA
Rear Axle
Height : 76 mm
Diameter : 316 mm
Centering Diameter : 72 mm
Pitch Circle Diameter : 127 mm
Brake Disc Thickness : 12 mm
Minimum Thickness : 10.4 mm
Num. of holes : 5
Solid or Vented : S
Weight : 7 kg -
Front Axle
Height : 56.5 mm
Diameter : 328 mm
Centering Diameter : 69.1 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Num. of holes : 6
Solid or Vented : V -
Ref.:42431-48041
Rear Axle
Height : 69.6 mm
Diameter : 288 mm
Centering Diameter : 62.2 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8.6 mm
Num. of holes : 5
Solid or Vented : S
Weight : 5.1 kg -
Ref.:4743999AA
Rear Axle
Height : 60.2 mm
Diameter : 302 mm
Centering Diameter : 80 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8.5 mm
Num. of holes : 5
Solid or Vented : S
Weight : 5.3 kg -
Front Axle
Height : 43 mm
Diameter : 296 mm
Pitch Circle Diameter : 110 mm
Brake Disc Thickness : 26 mm
Minimum Thickness : 23 mm
Num. of holes : 5
Solid or Vented : V -
Rear Axle
Height : 41.7 mm
Diameter : 277.9 mm
Centering Diameter : 70 mm
Pitch Circle Diameter : 110 mm
Brake Disc Thickness : 12 mm
Minimum Thickness : 10 mm
Num. of holes : 5
Solid or Vented : S -
Front Axle
Height : 52.7 mm
Diameter : 326 mm
Centering Diameter : 58 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 30 mm
Minimum Thickness : 28 mm
Num. of holes : 5
Solid or Vented : V
Weight : 10.2 kg
