Professional and precise product catalogs will surely provide long-term, robust support for the sustained growth of your business performance.
Please contact us if you require the complete product catalog.
Catalog Search：
-
Ref.:8-97182-771-0
Front Axle
Height : 100.2 mm
Diameter : 363 mm
Centering Diameter : 110 mm
Pitch Circle Diameter : 136.7 mm
Brake Disc Thickness : 42.22 mm
Minimum Thickness : 39 mm
Num. of holes : 12
Solid or Vented : V
Weight : 18.6 kg -
Front Axle
Height : 105 mm
Diameter : 381 mm
Centering Diameter : 131.5 mm
Pitch Circle Diameter : 172 mm
Brake Disc Thickness : 39.1 mm
Minimum Thickness : 36.1 mm
Num. of holes : 5
Solid or Vented : V
Weight : 19.96 kg -
Front Axle
Height : 46.8 mm
Diameter : 255.8 mm
Centering Diameter : 60 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 24.13 mm
Minimum Thickness : 22.1 mm
Num. of holes : 4
Solid or Vented : V -
Front Axle
Height : 110.8 mm
Diameter : 390 mm
Centering Diameter : 125.1 mm
Pitch Circle Diameter : 170 mm
Brake Disc Thickness : 39 mm
Minimum Thickness : 37.4 mm
Num. of holes : 10
Solid or Vented : V
Weight : 19.68 kg -
Ref.:40206-1AA0A
Front Axle
Height : 49.2 mm
Diameter : 320 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Num. of holes : 5
Solid or Vented : V -
Front Axle, Left
Height : 50.7 mm
Diameter : 334 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 30 mm
Minimum Thickness : 28 mm
Num. of holes : 5
Solid or Vented : V -
Front Axle, Right
Height : 50.7 mm
Diameter : 334 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 30 mm
Minimum Thickness : 28 mm
Num. of holes : 5
Solid or Vented : V -
Rear Axle
Height : 48.1 mm
Diameter : 315 mm
Centering Diameter : 67.4 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 23 mm
Minimum Thickness : 21.5 mm
Number of Holes : 6
Solid or Vented : V -
Front Axle
Height : 56.5 mm
Diameter : 340 mm
Centering Diameter : 69 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Num. of holes : 5
Solid or Vented : V -
Ref.:40206-AZ60A
Front Axle
Height : 43.9 mm
Diameter : 259.8 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 20 mm
Num. of holes : 4
Solid or Vented : V
