Front Axle
Height : 49.1 mm
Diameter : 320 mm
Centering Diameter : 69 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26.4 mm
Number of Holes : 5
Solid Or Vented : V -
Front Axle
Height : 47 mm
Diameter : 296 mm
Centering Diameter : 64 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Number of Holes : 5
Solid Or Vented : V -
参考号:98115794
Rear Axle
Height : 80.2 mm
Diameter : 318 mm
Centering Diameter : 101 mm
Pitch Circle Diameter : 139.7 mm
Brake Disc Thickness : 18 mm
Minimum Thickness : 16.6 mm
Number of Holes : 6
Solid Or Vented : V -
参考号:DV513191
Rear Axle
Height : 41.1 mm
Diameter : 236 mm
Centering Diameter : 64 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8.4 mm
Number of Holes : 5
Solid Or Vented : S -
参考号:DV513189
Front Axle
Height : 46.1 mm
Diameter : 256 mm
Centering Diameter : 64 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 24 mm
Minimum Thickness : 22.4 mm
Number of Holes : 5
Solid Or Vented : V -
参考号:40206-AN000
Front Axle
Height : 45.2 mm
Diameter : 237.8 mm
Centering Diameter : 59 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 20 mm
Number of Holes : 4
Solid Or Vented : V -
Rear Axle
Height : 31.1 mm
Diameter : 259 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8 mm
Number of Holes : 5
Solid Or Vented : S -
Front Axle
Height : 47 mm
Diameter : 276 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 26 mm
Minimum Thickness : 24 mm
Number of Holes : 5
Solid Or Vented : V -
Front Axle
Height : 41.7 mm
Diameter : 229 mm
Centering Diameter : 64 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 17 mm
Minimum Thickness : 15.4 mm
Number of Holes : 4
Solid Or Vented : V -
Front Axle
Height : 61 mm
Diameter : 302 mm
Centering Diameter : 98 mm
Pitch Circle Diameter : 139.7 mm
Brake Disc Thickness : 32 mm
Minimum Thickness : 30 mm
Number of Holes : 6
Solid Or Vented : V
