Ref.:93188916
Front Axle
Height : 40.5 mm
Diameter : 257 mm
Centering Diameter : 60 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 12.0 mm
Minimum Thickness : 10 mm
Num. of holes : 4
Solid or Vented : S
Weight : 4 kg -
Ref.:451 421 01 12
Front Axle
Height : 38 mm
Diameter : 280 mm
Centering Diameter : 58 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 9.6 mm
Minimum Thickness : 8 mm
Num. of holes : 3
Solid or Vented : S -
Ref.:5 69 418
Rear Axle
Height : 40.5 mm
Diameter : 264 mm
Centering Diameter : 70 mm
Pitch Circle Diameter : 110 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.7 kg -
Ref.:60800345
Rear Axle
Height : 40 mm
Diameter : 240.5 mm
Centering Diameter : 59 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 11.0 mm
Minimum Thickness : 9.2 mm
Num. of holes : 4
Solid or Vented : S
Weight : 3.33 kg -
Ref.:UR6133251
Front Axle
Height : 70.3 mm
Diameter : 288.7 mm
Centering Diameter : 98 mm
Pitch Circle Diameter : 139.7 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Num. of holes : 6
Solid or Vented : V -
Ref.:43512-12611
Front Axle
Height : 49.3 mm
Diameter : 254.9 mm
Centering Diameter : 55 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 20 mm
Num. of holes : 4
Solid or Vented : V -
Front Axle
Height : 48.6 mm
Diameter : 285 mm
Centering Diameter : 105 mm
Pitch Circle Diameter : 127 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Num. of holes : 6
Solid or Vented : V -
Ref.:MN102276
Front Axle
Height : 46.4 mm
Diameter : 294 mm
Centering Diameter : 94 mm
Pitch Circle Diameter : 139.7 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26.4 mm
Num. of holes : 6
Solid or Vented : V -
Rear Axle
Height : 102.5 mm
Diameter : 311.9 mm
Centering Diameter : 106 mm
Pitch Circle Diameter : 174 mm
Brake Disc Thickness : 18 mm
Minimum Thickness : 16 mm
Num. of holes : 6
Solid or Vented : V -
Ref.:42510-SWW-G01
Rear Axle
Height : 61 mm
Diameter : 302 mm
Centering Diameter : 64.1 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
