Front Axle
Height : 49 mm
Diameter : 321 mm
Centering Diameter : 69 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26.4 mm
Num. of holes : 5
Solid or Vented : V
Weight : 10.2 kg -
Ref.:2992635
Rear Axle
Height : 151.3 mm
Diameter : 377 mm
Centering Diameter : 225 mm
Pitch Circle Diameter : 275 mm
Brake Disc Thickness : 45 mm
Minimum Thickness : 37 mm
Num. of holes : 8
Solid or Vented : V
Weight : 33.6 kg -
Ref.:2992636
Rear Axle
Height : 151.3 mm
Diameter : 377 mm
Centering Diameter : 225 mm
Pitch Circle Diameter : 275 mm
Brake Disc Thickness : 45 mm
Minimum Thickness : 37 mm
Num. of holes : 8
Solid or Vented : V
Weight : 34.1 kg -
Ref.:7183804
Front Axle
Height : 151.3 mm
Diameter : 377 mm
Centering Diameter : 215 mm
Pitch Circle Diameter : 275 mm
Brake Disc Thickness : 45 mm
Minimum Thickness : 37 mm
Num. of holes : 8
Solid or Vented : V
Weight : 33.2 kg -
Ref.:7183805
Front Axle
Height : 151.3 mm
Diameter : 377 mm
Centering Diameter : 215 mm
Pitch Circle Diameter : 275 mm
Brake Disc Thickness : 45 mm
Minimum Thickness : 37 mm
Num. of holes : 8
Solid or Vented : V
Weight : 33.8 kg -
Ref.:7172928
Front Axle
Height : 181.5 mm
Diameter : 370 mm
Centering Diameter : 215 mm
Pitch Circle Diameter : 275 mm
Brake Disc Thickness : 45 mm
Minimum Thickness : 41 mm
Num. of holes : 8
Solid or Vented : V
Weight : 34.8 kg -
Ref.:7172880
Front Axle
Height : 150 mm
Diameter : 370 mm
Centering Diameter : 215 mm
Pitch Circle Diameter : 275 mm
Brake Disc Thickness : 45 mm
Minimum Thickness : 41 mm
Num. of holes : 8
Solid or Vented : V
Weight : 32.9 kg -
Ref.:356 421 12 12
Front Axle, Rear Axle
Height : 135 mm
Diameter : 438 mm
Centering Diameter : 195 mm
Pitch Circle Diameter : 235 mm
Brake Disc Thickness : 45 mm
Minimum Thickness : 41 mm
Num. of holes : 10
Solid or Vented : V
Weight : 33.3 kg -
Ref.:2996419
Front Axle
Height : 129.5 mm
Diameter : 330 mm
Centering Diameter : 185 mm
Pitch Circle Diameter : 245 mm
Brake Disc Thickness : 32 mm
Minimum Thickness : 29 mm
Num. of holes : 6
Solid or Vented : V
Weight : 17.9 kg -
Ref.:2996418
Rear Axle
Height : 129.5 mm
Diameter : 330 mm
Centering Diameter : 185 mm
Pitch Circle Diameter : 245 mm
Brake Disc Thickness : 32 mm
Minimum Thickness : 29 mm
Num. of holes : 6
Solid or Vented : V
Weight : 19.1 kg
