Professional and precise product catalogs will surely provide long-term, robust support for the sustained growth of your business performance.
Please contact us if you require the complete product catalog.
Catalog Search：
-
Ref.:42510-S9A-N00
Rear Axle
Height : 58.3 mm
Diameter : 282 mm
Centering Diameter : 64.1 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 9 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 4.2 kg -
Ref.:4509 553AB
Rear Axle
Height : 53.3 mm
Diameter : 270 mm
Centering Diameter : 57.5 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 9.0 mm
Minimum Thickness : 7.3 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.8 kg -
Rear Axle
Height : 46.5 mm
Diameter : 258 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 9.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.6 kg -
Ref.:42431-20360
Rear Axle
Height : 65 mm
Diameter : 269 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 9.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 4 kg -
Ref.:4246.Z9
Rear Axle
Height : 67.1 mm
Diameter : 249 mm
Pitch Circle Diameter : 108 mm
Brake Disc Thickness : 9.0 mm
Minimum Thickness : 8 mm
Num. of holes : 4
Solid or Vented : S
Weight : 5.1 kg -
Ref.:42510-SCA-E50
Rear Axle
Height : 61 mm
Diameter : 304.5 mm
Centering Diameter : 64.3 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 9 mm
Minimum Thickness : 7.5 mm
Num. of holes : 5
Solid or Vented : S -
Ref.:42431-42040
Rear Axle
Height : 62.1 mm
Diameter : 303 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 9.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S -
Ref.:4246 63
Front Axle
Height : 39.4 mm
Diameter : 241 mm
Pitch Circle Diameter : 86 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 9 mm
Num. of holes : 3
Solid or Vented : S
Weight : 3.3 kg -
Ref.:55511-82000
Front Axle
Height : 33.4 mm
Diameter : 215.1 mm
Pitch Circle Diameter : 102 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8 mm
Num. of holes : 4
Solid or Vented : S
Weight : 2.5 kg -
Ref.:77 01 466 540
Front Axle
Height : 38.5 mm
Diameter : 228 mm
Centering Diameter : 83.1 mm
Pitch Circle Diameter : 99 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 9 mm
Num. of holes : 6
Solid or Vented : S
Weight : 2.8 kg
