Ref.:3B7 615 301 B
Front Axle, Left
Height : 52.5 mm
Diameter : 334 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 32 mm
Minimum Thickness : 30 mm
Num. of holes : 10
Solid or Vented : V
Weight : 10.85 kg -
Ref.:3B7 615 302 B
Front Axle, Right
Height : 52.5 mm
Diameter : 334 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 32 mm
Minimum Thickness : 30 mm
Num. of holes : 10/10
Solid or Vented : V
Weight : 10.85 kg -
Ref.:677 920 93
Rear Axle
Height : 115 mm
Diameter : 322 mm
Centering Diameter : 164 mm
Pitch Circle Diameter : 190 mm
Brake Disc Thickness : 30 mm
Minimum Thickness : 28 mm
Num. of holes : 6
Solid or Vented : V
Weight : 13.8 kg -
Front Axle
Height : 127.2 mm
Diameter : 438 mm
Centering Diameter : 195 mm
Pitch Circle Diameter : 235 mm
Brake Disc Thickness : 45 mm
Minimum Thickness : 38 mm
Num. of holes : 10
Solid or Vented : V
Weight : 34.88 kg -
Rear Axle, Left
Height : 68 mm
Diameter : 322 mm
Centering Diameter : 103 mm
Pitch Circle Diameter : 130 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Num. of holes : 5
Solid or Vented : P/V
Weight : 8.26 kg -
Rear Axle, Right
Height : 68 mm
Diameter : 322 mm
Centering Diameter : 103 mm
Pitch Circle Diameter : 130 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Num. of holes : 5
Solid or Vented : P/V
Weight : 8.26 kg -
Front Axle, Left
Height : 46.5 mm
Diameter : 360 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 32 mm
Minimum Thickness : 30.4 mm
Num. of holes : 5
Solid or Vented : P/V
Weight : 11.9 kg -
Front Axle, Right
Height : 46.5 mm
Diameter : 360 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 32 mm
Minimum Thickness : 30.4 mm
Num. of holes : 5
Solid or Vented : P/V
Weight : 11.9 kg -
Rear Axle, Left
Height : 45 mm
Diameter : 312 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 20.4 mm
Num. of holes : 5
Solid or Vented : P/V
Weight : 5.2 kg -
Rear Axle, Right
Height : 45 mm
Diameter : 312 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 20.4 mm
Num. of holes : 5
Solid or Vented : P/V
Weight : 5.2 kg
