Ref.:246 421 24 12
Front Axle
Height : 51 mm
Diameter : 295 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 25.4 mm
Number Of Holes : 5
Solid Or Vented : V
Weight : 8.2 kg -
Ref.:246 423 01 12
Rear Axle
Height : 44 mm
Diameter : 295 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8.3 mm
Number Of Holes : 5
Solid Or Vented : S
Weight : 4.5 kg -
Front Axle
Height : 44 mm
Diameter : 269 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 22.5 mm
Minimum Thickness : 19.8 mm
Number Of Holes : 5
Solid Or Vented : V
Weight : 5.5 kg -
Front Axle
Height : 55.5 mm
Diameter : 340 mm
Centering Diameter : 76.2 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 32.5 mm
Minimum Thickness : 28.5 mm
Number Of Holes : 5
Solid Or Vented : V
Weight : 12.2 kg -
Ref.:40206-EE52A
Front Axle
Height : 44 mm
Diameter : 260 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 20 mm
Number Of Holes : 4
Solid Or Vented : V
Weight : 4.7 kg -
Ref.:40206-JX00A
Front Axle
Height : 53.7 mm
Diameter : 257 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 26 mm
Minimum Thickness : 24 mm
Number Of Holes : 4
Solid Or Vented : V
Weight : 6.2 kg -
Ref.:45251-TA1-A01
Front Axle
Height : 47.2 mm
Diameter : 300 mm
Centering Diameter : 64.2 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Number Of Holes : 5
Solid Or Vented : V
Weight : 8.1 kg -
Ref.:230 423 07 12
Rear Axle
Height : 58.3 mm
Diameter : 300 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8.3 mm
Number Of Holes : 5
Solid Or Vented : S
Weight : 4.9 kg -
Ref.:43206-00Q0A
Rear Axle
Height : 71.5 mm
Diameter : 305 mm
Centering Diameter : 90 mm
Pitch Circle Diameter : 130 mm
Brake Disc Thickness : 12 mm
Minimum Thickness : 10.5 mm
Number Of Holes : 5
Solid Or Vented : S
Weight : 6.5 kg -
Ref.:55211-76J00
Front Axle
Height : 46 mm
Diameter : 289.5 mm
Centering Diameter : 108 mm
Pitch Circle Diameter : 139.7 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8 mm
Number Of Holes : 5
Solid Or Vented : S
Weight : 4.4 kg
