Ref.:000 423 11 12
Rear Axle
Height : 68.3 mm
Diameter : 320 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 24 mm
Minimum Thickness : 21.4 mm
Number Of Holes : 5
Solid Or Vented : V
Weight : 8.2 kg -
Ref.:43206-MB600
Rear Axle
Height : 62.2 mm
Diameter : 280 mm
Centering Diameter : 108 mm
Pitch Circle Diameter : 127 mm
Brake Disc Thickness : 16 mm
Minimum Thickness : 13 mm
Number Of Holes : 6
Solid Or Vented : V
Weight : 6.5 kg -
Ref.:43206-MB60A
Rear Axle
Height : 67 mm
Diameter : 280 mm
Centering Diameter : 108 mm
Pitch Circle Diameter : 127 mm
Brake Disc Thickness : 16 mm
Minimum Thickness : 13 mm
Number Of Holes : 6
Solid Or Vented : V
Weight : 7 kg -
Front Axle
Height : 77.5 mm
Diameter : 297 mm
Centering Diameter : 85 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 19 mm
Number Of Holes : 6
Solid Or Vented : S -
Ref.:000 423 16 12
Rear Axle
Height : 43 mm
Diameter : 300 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10 mm
Minimum Thickness : 8.3 mm
Number Of Holes : 5
Solid Or Vented : S
Weight : 4.6 kg -
Ref.:51854567
Front Axle
Height : 45.7 mm
Diameter : 305 mm
Centering Diameter : 59 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Number Of Holes : 5
Solid Or Vented : V
Weight : 7.7 kg -
Ref.:569068
Front Axle
Height : 49.9 mm
Diameter : 355 mm
Centering Diameter : 67.4 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 32 mm
Minimum Thickness : 30 mm
Number Of Holes : 5
Solid Or Vented : P/V
Weight : 9.8 kg -
Ref.:219 421 02 12
Front Axle
Height : 64.5 mm
Diameter : 360 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 36 mm
Minimum Thickness : 33 mm
Number Of Holes : 5
Solid Or Vented : P/V
Weight : 13.2 kg -
Ref.:8-98124-663-3
Front Axle
Height : 40 mm
Diameter : 300 mm
Centering Diameter : 88 mm
Brake Disc Thickness : 27 mm
Minimum Thickness : 25 mm
Number of Holes : 6
Solid Or Vented : V -
Ref.:51712-2V000
Front Axle
Height : 44.5 mm
Diameter : 280 mm
Centering Diameter : 69 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 23 mm
Minimum Thickness : 21.4 mm
Number Of Holes : 5
Solid Or Vented : V
Weight : 6.2 kg
