Ref.:251 407 617 K
Front Axle
Height : 95.7 mm
Diameter : 258 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 15.9 mm
Minimum Thickness : 14 mm
Num. of holes : 5
Solid or Vented : S
Weight : 7.7 kg -
Ref.:251 407 617 A
Front Axle
Height : 118.5 mm
Diameter : 278 mm
Centering Diameter : 45.2 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 13.0 mm
Minimum Thickness : 11 mm
Num. of holes : 5
Solid or Vented : S
Weight : 8.8 kg -
Ref.:220 423 01 12
Rear Axle
Height : 58.5 mm
Diameter : 300 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 11.0 mm
Minimum Thickness : 9.3 mm
Num. of holes : 5
Solid or Vented : S
Weight : 5.1 kg -
Ref.:220 421 09 12
Front Axle
Height : 76 mm
Diameter : 312 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 28.0 mm
Minimum Thickness : 26 mm
Num. of holes : 5
Solid or Vented : P/V
Weight : 8.6 kg -
Ref.:211 421 07 12
Front Axle
Height : 54.5 mm
Diameter : 295.5 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 28.0 mm
Minimum Thickness : 25.4 mm
Num. of holes : 5
Solid or Vented : V
Weight : 7.32 kg -
Ref.:210 423 08 12
Rear Axle
Height : 55 mm
Diameter : 300 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 19.4 mm
Num. of holes : 5
Solid or Vented : V
Weight : 7 kg -
Ref.:210 423 07 12
Rear Axle
Height : 55.5 mm
Diameter : 300 mm
Centering Diameter : 67 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 22.0 mm
Minimum Thickness : 19.4 mm
Num. of holes : 5
Solid or Vented : V -
Ref.:1K0 615 601 N
Rear Axle
Height : 48.5 mm
Diameter : 310 mm
Centering Diameter : 65 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 22.0 mm
Minimum Thickness : 20 mm
Solid or Vented : V
Weight : 6.8 kg -
Ref.:1K0 615 601 L
Rear Axle
Height : 48.3 mm
Diameter : 260 mm
Centering Diameter : 65 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 11.6 mm
Minimum Thickness : 10 mm
Num. of holes : 5
Solid or Vented : S
Weight : 4.2 kg -
Ref.:1K0 615 601 K
Rear Axle
Height : 51.6 mm
Diameter : 255 mm
Centering Diameter : 65 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8 mm
Solid or Vented : S
Weight : 3.6 kg
