Ref.:45251-S84-A01
Front Axle
Height : 47 mm
Diameter : 260 mm
Centering Diameter : 64.2 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 23 mm
Minimum Thickness : 21.46 mm
Num. of holes : 4
Solid or Vented : V
Weight : 5.1 kg -
Front Axle
Height : 51.1 mm
Diameter : 261.4 mm
Centering Diameter : 64.3 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 21.1 mm
Minimum Thickness : 19 mm
Num. of holes : 4
Solid or Vented : V -
Ref.:45251-SG0-J00
Front Axle
Height : 51.5 mm
Diameter : 282 mm
Centering Diameter : 64.2 mm
Pitch Circle Diameter : 114 mm
Brake Disc Thickness : 21 mm
Minimum Thickness : 19 mm
Num. of holes : 4
Solid or Vented : V
Weight : 6.25 kg -
Ref.:45251-SM4-G02
Front Axle
Height : 34 mm
Diameter : 282 mm
Centering Diameter : 92 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 23.0 mm
Minimum Thickness : 21 mm
Num. of holes : 4
Solid or Vented : V
Weight : 6.2 kg -
Front Axle
Height : 47 mm
Diameter : 282 mm
Centering Diameter : 70.2 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28.0 mm
Minimum Thickness : 26 mm
Num. of holes : 5
Solid or Vented : V
Weight : 7.2 kg -
Ref.:51712-21300
Front Axle
Height : 39.4 mm
Diameter : 229 mm
Centering Diameter : 86 mm
Pitch Circle Diameter : 104 mm
Brake Disc Thickness : 13.0 mm
Minimum Thickness : 11.4 mm
Num. of holes : 4
Solid or Vented : V
Weight : 3.35 kg -
Ref.:51712-24100
Front Axle
Height : 41 mm
Diameter : 242 mm
Centering Diameter : 86 mm
Pitch Circle Diameter : 104 mm
Brake Disc Thickness : 19 mm
Minimum Thickness : 17.7 mm
Num. of holes : 4
Solid or Vented : V
Weight : 4.25 kg -
Ref.:34 11 1 117 422
Front Axle
Height : 58.5 mm
Diameter : 240 mm
Centering Diameter : 63 mm
Pitch Circle Diameter : 80 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8.4 mm
Num. of holes : 4
Solid or Vented : S
Weight : 3.5 kg -
Ref.:34 11 1 154 974
Front Axle
Height : 78 mm
Diameter : 280 mm
Centering Diameter : 74 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 25.0 mm
Minimum Thickness : 23.4 mm
Num. of holes : 5
Solid or Vented : V
Weight : 6.1 kg -
Front Axle
Height : 76.4 mm
Diameter : 299 mm
Centering Diameter : 78.8 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 30.0 mm
Minimum Thickness : 28.4 mm
Num. of holes : 5
Solid or Vented : V
