Catalog Search：
-
Ref.:43512-20730
Front Axle
Height : 49.2 mm
Diameter : 276 mm
Centering Diameter : 55 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 25.0 mm
Minimum Thickness : 23 mm
Num. of holes : 5
Solid or Vented : V
Weight : 7 kg -
Ref.:43512-02080
Front Axle
Height : 49.2 mm
Diameter : 275 mm
Centering Diameter : 55 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 25.0 mm
Minimum Thickness : 23 mm
Num. of holes : 4
Solid or Vented : V
Weight : 6 kg -
Front Axle
Height : 62.2 mm
Diameter : 325 mm
Centering Diameter : 75 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 25.0 mm
Minimum Thickness : 23.4 mm
Num. of holes : 5
Solid or Vented : V
Weight : 9.1 kg -
Ref.:45251-S6M-A10
Front Axle
Height : 47.2 mm
Diameter : 300 mm
Centering Diameter : 64.1 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 25.0 mm
Minimum Thickness : 23 mm
Num. of holes : 5
Solid or Vented : V
Weight : 6.9 kg -
Ref.:1815204850
Front Axle
Height : 48.5 mm
Diameter : 320 mm
Centering Diameter : 63.5 mm
Pitch Circle Diameter : 108 mm
Brake Disc Thickness : 25.0 mm
Minimum Thickness : 23 mm
Num. of holes : 5
Solid or Vented : V
Weight : 9.6 kg -
Front Axle
Height : 39.7 mm
Diameter : 300 mm
Centering Diameter : 70.2 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 25.0 mm
Minimum Thickness : 23 mm
Num. of holes : 5
Solid or Vented : V -
Ref.:40206-9C100
Front Axle
Height : 52.5 mm
Diameter : 257 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 26.0 mm
Minimum Thickness : 24 mm
Num. of holes : 5
Solid or Vented : V
Weight : 6.7 kg -
Front Axle
Height : 45.5 mm
Diameter : 257 mm
Centering Diameter : 61 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 26.0 mm
Minimum Thickness : 24 mm
Num. of holes : 4
Solid or Vented : V
Weight : 6.2 kg -
Ref.:60814639
Front Axle
Height : 47.5 mm
Diameter : 281 mm
Centering Diameter : 59 mm
Pitch Circle Diameter : 108 mm
Brake Disc Thickness : 26.0 mm
Minimum Thickness : 24.2 mm
Num. of holes : 10
Solid or Vented : V
Weight : 6.7 kg -
Front Axle
Height : 54.2 mm
Diameter : 281 mm
Centering Diameter : 59 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 26.0 mm
Minimum Thickness : 24.2 mm
Num. of holes : 5
Solid or Vented : V
Weight : 7.0 kg
