Ref.:77 01 204 290
Rear Axle
Height : 31 mm
Diameter : 255 mm
Centering Diameter : 66 mm
Pitch Circle Diameter : 108 mm
Brake Disc Thickness : 11 mm
Minimum Thickness : 9.5 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.3 kg -
Rear Axle
Height : 45 mm
Diameter : 279 mm
Centering Diameter : 120 mm
Pitch Circle Diameter : 136 mm
Brake Disc Thickness : 9 mm
Minimum Thickness : 8.1 mm
Num. of holes : 6
Solid or Vented : S
Weight : 3.73 kg -
Ref.:5489362D
Rear Axle
Height : 57 mm
Diameter : 224 mm
Centering Diameter : 58 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 7 mm
Minimum Thickness : 5 mm
Num. of holes : 5
Solid or Vented : S
Weight : 2.56 kg -
Ref.:0017740314
Front Axle
Height : 27 mm
Diameter : 240 mm
Centering Diameter : 75 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 11 mm
Minimum Thickness : 9.9 mm
Num. of holes : 4
Solid or Vented : S
Weight : 3.2 kg -
Ref.:25407214
Front Axle
Height : 27 mm
Diameter : 240 mm
Centering Diameter : 75 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 13 mm
Minimum Thickness : 11.7 mm
Num. of holes : 4
Solid or Vented : S
Weight : 3.54 kg -
Ref.:40206-01B01
Front Axle
Height : 43.2 mm
Diameter : 214 mm
Centering Diameter : 59 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 12.0 mm
Minimum Thickness : 10 mm
Num. of holes : 4
Solid or Vented : S
Weight : 3.1 kg -
Ref.:90063312
Rear Axle
Height : 83.2 mm
Diameter : 279 mm
Centering Diameter : 70 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 10.4 mm
Minimum Thickness : 9.5 mm
Solid or Vented : S -
Ref.:1 549 703
Front Axle
Height : 73 mm
Diameter : 262 mm
Centering Diameter : 69 mm
Pitch Circle Diameter : 95 mm
Brake Disc Thickness : 24 mm
Minimum Thickness : 22.6 mm
Num. of holes : 5
Solid or Vented : V
Weight : 5.93 kg -
Ref.:72GB1125HB
Front Axle
Height : 73 mm
Diameter : 262 mm
Centering Diameter : 69 mm
Pitch Circle Diameter : 95 mm
Brake Disc Thickness : 13 mm
Minimum Thickness : 11.4 mm
Num. of holes : 5
Solid or Vented : S
Weight : 5.43 kg -
Ref.:5 022 673
Front Axle
Height : 32 mm
Diameter : 245 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 92 mm
Brake Disc Thickness : 20 mm
Minimum Thickness : 18.5 mm
Num. of holes : 4
Solid or Vented : V
