Professional and precise product catalogs will surely provide long-term, robust support for the sustained growth of your business performance.
Please contact us if you require the complete product catalog.
Catalog Search：
-
Front Axle
Height : 55 mm
Diameter : 252 mm
Centering Diameter : 80 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 9 mm
Minimum Thickness : 8 mm
Num. of holes : 4
Solid or Vented : S
Weight : 3.5 kg -
Ref.:7328067
Front Axle
Height : 51 mm
Diameter : 267 mm
Centering Diameter : 98 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 9.5 mm
Minimum Thickness : 8 mm
Solid or Vented : S -
Front Axle
Height : 70.7 mm
Diameter : 280 mm
Centering Diameter : 86.1 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 20.1 mm
Minimum Thickness : 18.9 mm
Num. of holes : 4
Solid or Vented : V
Weight : 5.620 kg -
Ref.:2708758
Front Axle
Height : 72 mm
Diameter : 280 mm
Centering Diameter : 65 mm
Pitch Circle Diameter : 108 mm
Brake Disc Thickness : 14 mm
Minimum Thickness : 11.5 mm
Num. of holes : 5
Solid or Vented : S
Weight : 7.35 kg -
Ref.:46445005
Front Axle
Height : 50.7 mm
Diameter : 257.2 mm
Centering Diameter : 59 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 22.0 mm
Minimum Thickness : 20.2 mm
Num. of holes : 4
Solid or Vented : V
Weight : 5.4 kg -
Ref.:795036
Rear Axle
Height : 82 mm
Diameter : 233 mm
Centering Diameter : 39.1 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 9 mm
Minimum Thickness : 7.8 mm
Num. of holes : 4
Solid or Vented : S
Weight : 5.1 kg -
Rear Axle
Height : 40 mm
Diameter : 240 mm
Centering Diameter : 59 mm
Pitch Circle Diameter : 96 mm
Brake Disc Thickness : 11 mm
Minimum Thickness : 9.2 mm
Num. of holes : 2
Solid or Vented : S
Weight : 3.20 kg -
Ref.:82462136
Front Axle
Height : 39.4 mm
Diameter : 284 mm
Centering Diameter : 59 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 22.0 mm
Minimum Thickness : 20.2 mm
Num. of holes : 4
Solid or Vented : V
Weight : 6 kg -
Ref.:8582290
Front Axle
Height : 112 mm
Diameter : 267 mm
Centering Diameter : 58.3 mm
Pitch Circle Diameter : 95 mm
Brake Disc Thickness : 14 mm
Minimum Thickness : 12.8 mm
Num. of holes : 6
Solid or Vented : S
Weight : 12.4 kg -
Ref.:82346805
Front Axle
Height : 66 mm
Diameter : 251 mm
Centering Diameter : 49 mm
Pitch Circle Diameter : 98 mm
Brake Disc Thickness : 13 mm
Minimum Thickness : 11.5 mm
Num. of holes : 4
Solid or Vented : S
Weight : 4.34 kg
