Professional and precise product catalogs will surely provide long-term, robust support for the sustained growth of your business performance.
Please contact us if you require the complete product catalog.
Catalog Search：
-
Ref.:4F0 615 301 G
Front Axle
Height : 59.7 mm
Diameter : 347 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 30.0 mm
Minimum Thickness : 28 mm
Num. of holes : 5
Solid or Vented : V
Weight : 11.1 kg -
Ref.:4F0 615 301 E
Front Axle
Height : 59.7 mm
Diameter : 321 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 30 mm
Minimum Thickness : 28 mm
Num. of holes : 5
Solid or Vented : V
Weight : 10.2 kg -
Ref.:4F0 615 301 D
Front Axle
Height : 59.7 mm
Diameter : 314 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 25.0 mm
Minimum Thickness : 23 mm
Num. of holes : 5
Solid or Vented : V
Weight : 8.7 kg -
Rear Axle
Height : 48.1 mm
Diameter : 255 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.5 kg -
Rear Axle
Height : 54.1 mm
Diameter : 255 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.5 kg -
Rear Axle
Height : 54.1 mm
Diameter : 245 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.4 kg -
Ref.:4A0 615 601 A
Rear Axle
Height : 64.2 mm
Diameter : 245 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 10.0 mm
Minimum Thickness : 8 mm
Num. of holes : 5
Solid or Vented : S
Weight : 3.64 kg -
Ref.:4A0 615 301 C
Front Axle
Height : 46.5 mm
Diameter : 288 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 25 mm
Minimum Thickness : 23 mm
Solid or Vented : V
Weight : 7.4 kg -
Ref.:4A0 615 301 B
Front Axle
Height : 46.5 mm
Diameter : 288 mm
Centering Diameter : 68 mm
Pitch Circle Diameter : 112 mm
Brake Disc Thickness : 15.0 mm
Minimum Thickness : 13 mm
Num. of holes : 5
Solid or Vented : S
Weight : 6.25 kg -
Ref.:4700 711
Front Axle
Height : 44 mm
Diameter : 247 mm
Centering Diameter : 60 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 12.0 mm
Minimum Thickness : 10.5 mm
Num. of holes : 4
Solid or Vented : S
Weight : 4 kg
